Directional full coverage array antenna system

Directional airspace full coverage reconnaissance and direction finding array antenna system

Product Introduction

This product is an array antenna system developed for three major global satellite communication systems, capable of receiving more than 10 beams simultaneously. The antenna system adopts an omnidirectional array design scheme to ensure full spatial coverage of the antenna pattern. The frequencies of 10 incoming signals are respectively amplified, filtered, and converted to 10 intermediate frequency segments through radio frequency, with a total bandwidth within 400M after splicing, and the intermediate frequency output is 750M (customizable), then processed by the receiver. This antenna system can be widely used in fields such as reconnaissance and direction finding.

Product Features

Multi-channel, high gain, miniaturized;
High mutual coupling isolation characteristics;
High integration, low cost, one receiver processes more than 10 signals;

Specifications

Index	Parameter
Frequency Range	L band, customizable
Phase Noise	≤ 65dBc/1kHz
Antenna Beam	Azimuth 0°～360°; Elevation -20°～90°
Voltage Standing Wave Ratio (VSWR)	≤2 (50Ω)
Gain	Antenna ≥15dBic, RF ≥40dB
Intermediate Frequency Output	750MHz±200MHz, customizable
Antenna Size	≤100010001000mm
