Satellite-borne multi-purpose antenna

Product Introduction

This product is a new type of "high-gain beamforming circularly polarized helical antenna", featuring wide beam, high gain, light weight, etc., and can be widely used in fields such as missiles, rockets, satellites, ships, equipment, and reconnaissance.

Product Features

Designed to meet the six requirements, with high reliability;
High gain in horizontal direction, miniaturized;
Used in half-space or ultra-wide space;

Specifications

Index	Parameter
Frequency Range	GNSS bands, etc., customizable
Polarization Mode	Left, right-hand circular polarization; linear polarization
Antenna Beam	Upper half-space, customizable
Voltage Standing Wave Ratio (VSWR)	≤1.5 (50Ω)
Gain	≥3dBic, customizable
Operating Temperature	-200℃~200℃, customizable
Antenna Size	customizable
